OVERVIEW
PCTFRS6LMG is built on PCT’s patented compression technology, the PCT-FRS-6LMG delivers ultimate performance with cost efficiency. Featuring torque retaining and continuous ground design with a 21mm compression length, this compact F-type RG-6 connector ensures clean contact, reduced return loss, and reliable AV signal transmission—perfect for professional and residential installs demanding durability and signal integrity
SPECIFICATIONS
Feature Details Connector Type FRS Compression Connector Gender Male Cable Compatibility Series 6 Cable (RG6), supports 60% through Tri-Shield or Quad-Shield cable types Impedance 75 Ohms Construction Material 100% Brass construction (body, post, nut), corrosion-resistant plating Compression Mechanism Patented Metal Compression Ring technology that locks polymer sleeve in place and prevents loosening Weather Protection Dual O-Ring design, UV stabilized polymer sleeve for moisture and UV resistance Tool Compatibility Compatible with common 21 mm stroke compression tools such as PCT-RHXL-CT-AS, PCT-CT-RH, Ripley CT2-AS Application Use High-performance broadband, CATV, satellite, DOCSIS 3.1-4.0 systems; tested for harsh environmental conditions Packaging A bag of 50 pcs DOWNLOAD
Click to view - Product Data Sheet
